PIXA
Light-conducting channels in PIXA create a unique, light-filtering screen. Also available as dimensional slabs and panels which are punctuated with light pillars that pierce the terrazzo substrate. A secondary, “floating” surface comes to life with dynamic visual output created by light, shadow, movement, and colors.
NEW! PIXA Sphere Dimensional
PIXA™ Dimensional was first introduced in October 2017, featuring light pillars of uniform height that created a secondary surface parallel to the terrazzo. In the latest update, varying the heights of the light pillars enables additional shaping of the secondary surface, adding a new dimension to the material and unlocking a wealth of customizable features that push the boundaries of versatility. A single shape can serve as the focal point, or different shapes and sizes can be nested within each other or within the panel. The intricacy of the production process has increased significantly in this new configuration, where each individual light pillar is unique and occupies its own specific place within the panel, unlike more standard placements. The meticulously handcrafted and individually cast slabs are finished with a sandblasted texture, enhancing the primary surface's rustic appeal when illuminated. For large-scale, multi-panel installations, not only can the scale of the pattern be adjusted, but elements can also be designed to flow seamlessly between panels, creating expansive, art-like illuminated architectural features.
Featured Applications
There is no precedent in the industry for this unique light-filtering, selectively transparent concrete that is available as sheets in a format as large as 4’x8’ and as sleek as ½” thick. PIXA Screens are designed for vertical applications, to divide spaces and create privacy, while using light to maintain a delightfully connected whole. PIXA extends, distributes and maximizes ambient and daytime light, while allowing for selective privacy. It is an effective light-diffuser and acoustic barrier. Scuff, scratch, and impact resistant, this durable material is Class A fire rated and has superior thermal and acoustic performance.
Branding
Our customizable materials are a fresh take on signage, wayfinding and brand element designs where cohesiveness, user experience and a unique visual identity must converge.
Screening
The dual effect of the material – privacy and selective light filtering gives the designer a novel tool to achieve and maximize the design goals of functionality, adaptability and efficiency for any space.
Colors
PIXA is available in a generous palette of standard colors. Light can also be used as a coloring agent, with active control enabled using RGB or RGBW light sources. This versatile and customizable material can be specified to blend in with surrounding finishes, or to be its own conspicuous feature.
Since PIXA conducts light, the material absorbs and reacts to the environment and its inhabitants; colors and textures in the space tend to get picked up within the transparent elements of PIXA. This inter-mingling provides a cohesive and dynamic element within the interior space.
Patterns
Various terminal shapes and sizes in Grid, Staggered Grid and Random orientations are standard pattern offerings. Complexity may be dialed up with closer and tighter placement of terminals for close-up and small-scale applications, while the edgy and distinct look of larger, more widely spaced light-emitting windows complement large-scale installations.
Patterns can be used and customized for distinctive brand elements, or in response to the intended “programming of the space” (i.e. Degree of screening; light transmission; acoustic performance).
Dimensional
Integral light filtering channels appear as windows on the surface, creating a stunning pixilation of light. In the dimensional variety these are replaced by light-pillars that yield a “floating” secondary surface. The transmission of visual input can be varied by size, shape and pattern.
Surface Finish
Surface finishes, from sandblasted to honed to polished, add the final touch to the material aesthetic.
Dimensional Slabs are available in a natural and unpolished or raw and sandblasted finishes.
Sealers
The choice of sealer is determined by how the surface will be used. Food safe sealers are used for kitchens, restaurants and bars.
Complete Design Solutions
PIXA is also offered as a complete packaged solution, with material, hardware and lighting provided as a kit-of-parts for a multitude of applications.
PIXA needs no sensors or electronics; but add backlighting and it transforms into an illuminated screen. Lighting effects range from simple lighting and signage to complex light shows via programmable LEDs.
Regrind to new materials
PIXA is carefully handcrafted and precision manufactured in small batches in Michigan, USA, using high-quality materials responsibly sourced from an established US-based supply chain. PIXA’s optical channels are almost entirely made of regrind that is a byproduct of the manufacture of our other materials.
As well as creating innovative, dynamic spaces, light-manipulating materials will not emit volatile organic compounds (VOCs) during their production or their lifecycle, making them safe for use in an interior environment. They are PVC- and formaldehyde-free and contain no chemicals of concern.
Third party verified Environmental Product Declaration (EPD's), Health Product Declaration (HPD)s as well as recycled content certification is available for our materials.
Options & Custom Services
PIXA as a video screen
Changes in the projected content can be used to achieve a diverse array of effects with the flick of a switch.
Reference swatches can be matched to create unique tones.
Polished, Honed and Sandblasted
Arrangement of terminals on the surface can be customized to the design intent of a project.
Metal or color inlays are perfect for branding and logo design.
Exposed edges and corners are finished to specified profiles.
The material can be cast into complex curves.
Design possibilities are expanded exponentially due to the ability to form into shapes.
Seamless shapes are possible. Size and shape will need to be evaluated for feasibility.
Lighting effects range from simple lighting and signage to complex light shows via programmable LEDs.
Sleek in design and engineered to have lightweight options, PIXA is able to be installed using a variety of commonly available hardware options.
Engraving on the surface makes the material a perfect solution for brand and signage design.
Varying the height and placement of light pillars opens up a number of design options.
5/8”, 7/8” and 1-1/4”
5/8”, 7/8” and 1-1/4”
5/8”, 7/8” and 1-1/4”
5/8”, 7/8” and 1-1/4”
Material Type
Light Filtering
Applications
Screening, feature walls, signage, horizontal and vertical surfacing
Industry
Commercial and residential
Environment
Indoor and limited outdoor
Illumination
Back lighting (optional)
Material Composition
Terrazzo with Micro-Concrete and Resin
Standard Size
upto 4’ x 8′
Material Thickness
5/8", 7/8" and 1-1/4"
Patterns
Diamond, Grid, Lattice, Oblique, Pinwheel, Sequence, Staggered Grid
Terminal Types & Sizes
Square: 1/8", 1/4", 3/8", 1/2"
Rectangular: 1/8"×1/4", 3/16"×3/8", 1/4"×1/2"
Color
A generous palette with over 60 standard fiber colors, available with and without aggregate.
Custom color matching available.
Finishes
Natural and Sandblasted
Back-lighting color and control options
While PIXA does not require paired lighting, the following options are available in back-lighting for special applications.
White in 2700k, 3000k, 4000k and 6500k.
RGBW, Tunable While and Addressable lighting.
Single Color systems can be on/off or 0-10V dimming.
Tunable, RGBW and addressable systems can be programmed and controlled via DMX or Dali protocols.
Video projection and display systems are also available.
